Acoustic Data

STC and OITC results determined in accordance with ASTM E 90, Laboratory Measurement of Airborne Sound Transmission of Building Partitions, and ASTM E 1332, Determination of Outdoor-Indoor Transmission Class.

Series: Forgent® Series Heritage Series Ultra Series VistaLuxe WD LINE

Forgent® Series

PRODUCT

GLASS

COMBO

STC

OITC

Report

Awnings
Insulated Glass, 3.1mm - 3.1mm
N/A
28
22
ESP025396P-6
Awnings
Insulated Glass, 5.7mm - 3.1mm
N/A
33
26
ESP025396P-10
Awnings
LAMI 80
N/A
34
28
ESP025396P-9
Awnings
LAMI 82
N/A
33
26
ESP025396P-7
Awnings
Triple Insulated Glass, 3.1mm - 3.1mm - 4.7mm
N/A
33
28
ESP025396P-8
Casements
Insulated Glass, 3.1mm - 3.1mm
N/A
27
22
ESP025396P-1
Casements
Insulated Glass, 5.7mm - 3.1mm
N/A
31
26
ESP025396P-3
Casements
LAMI 80
N/A
32
27
ESP025396P-4
Casements
LAMI 82
N/A
32
27
ESP025396P-5
Casements
Triple Insulated Glass, 3.1mm - 3.1mm - 4.7mm
N/A
33
27
ESP025396P-2
Picture Direct Set Casements
Insulated Glass, 3.9mm - 3.9mm
N/A
29
24
ESP025396P-21
Picture Direct Set Casements
Insulated Glass, 5.7mm - 3.1mm
N/A
31
25
ESP025396P-23
Picture Direct Set Casements
LAMI 83
N/A
35
30
ESP025396P-24
Picture Direct Set Casements
LAMI 85
N/A
33
29
ESP025396P-25
Picture Direct Set Casements
Triple Insulated Glass, 3.1mm - 3.1mm - 4.7mm
N/A
30
26
ESP025396P-22
Picture Sash Set Casements
Insulated Glass, 3.9mm - 3.9mm
N/A
30
24
ESP025396P-36
Picture Sash Set Casements
Insulated Glass, 5.7mm - 3.1mm
N/A
32
27
ESP025396P-39
Picture Sash Set Casements
LAMI 82
N/A
34
29
ESP025396P-38
Picture Sash Set Casements
Triple Insulated Glass, 3.1mm - 3.1mm - 4.7mm
N/A
32
28
ESP025396P-37
Sliding Patio Doors
Insulated Glass, 3.9mm - 3.9mm
N/A
29
23
ESP025396P-16
Sliding Patio Doors
LAMI 82
N/A
31
26
ESP025396P-20
Sliding Patio Doors
LAMI 84
N/A
32
28
ESP025396P-17
Sliding Patio Doors
Triple Insulated Glass, 3.1mm - 3.1mm - 3.1mm
N/A
28
22
ESP025396P-18
Direct Set New Construction Direct Sets
Insulated Glass, 3.9mm - 3.9mm
N/A
29
24
ESP025396P-26
Direct Set New Construction Direct Sets
Insulated Glass, 5.7mm - 3.1mm
N/A
30
25
ESP025396P-27
Direct Set New Construction Direct Sets
LAMI 81
N/A
34
30
ESP025396P-30
Direct Set New Construction Direct Sets
LAMI 82
N/A
35
29
ESP025396P-28
Direct Set New Construction Direct Sets
Triple Insulated Glass, 3.1mm - 3.1mm - 4.7mm
N/A
30
26
ESP025396P-29
New Construction Double Hungs
Insulated Glass, 3.1mm - 3.1mm
N/A
29
24
ESP025396P-12
New Construction Double Hungs
Insulated Glass, 5.7mm - 3.1mm
N/A
36
29
ESP025396P-15
New Construction Double Hungs
LAMI 80
N/A
36
30
ESP025396P-11
New Construction Double Hungs
LAMI 82
N/A
36
29
ESP025396P-14
New Construction Double Hungs
Triple Insulated Glass, 3.1mm - 3.1mm - 4.7mm
N/A
35
29
ESP025396P-13
Studio New Construction Double Hungs
Insulated Glass, 3.1mm - 3.1mm
N/A
29
24
ESP025396P-31
Studio New Construction Double Hungs
Insulated Glass, 5.7mm - 3.1mm
N/A
33
28
ESP025396P-32
Studio New Construction Double Hungs
LAMI 82
N/A
34
27
ESP025396P-33
Studio New Construction Double Hungs
LAMI 85
N/A
35
31
ESP025396P-35
Studio New Construction Double Hungs
Triple Insulated Glass, 3.1mm - 3.1mm - 4.7mm
N/A
33
28
ESP025396P-34
New Construction Sliding Windows
Insulated Glass, 3.1mm - 3.1mm
N/A
29
24
ESP025396P-41
New Construction Sliding Windows
Insulated Glass, 5.7mm - 3.1mm
N/A
36
30
ESP025396P-42
New Construction Sliding Windows
LAMI 80
N/A
35
30
ESP025396P-45
New Construction Sliding Windows
LAMI 82
N/A
34
29
ESP025396P-43
New Construction Sliding Windows
Triple Insulated Glass, 3.1mm - 3.1mm - 4.7mm
N/A
35
30
ESP025396P-44
Direct Set Replacement Direct Sets
Insulated Glass, 3.9mm - 3.9mm
N/A
29
24
ESP025396P-26
Direct Set Replacement Direct Sets
Insulated Glass, 5.7mm - 3.1mm
N/A
30
25
ESP025396P-27
Direct Set Replacement Direct Sets
LAMI 81
N/A
34
30
ESP025396P-30
Direct Set Replacement Direct Sets
LAMI 82
N/A
35
29
ESP025396P-28
Direct Set Replacement Direct Sets
Triple Insulated Glass, 3.1mm - 3.1mm - 4.7mm
N/A
30
26
ESP025396P-29
Replacement Double Hungs
Insulated Glass, 3.1mm - 3.1mm
N/A
29
24
ESP025396P-12
Replacement Double Hungs
Insulated Glass, 5.7mm - 3.1mm
N/A
36
29
ESP025396P-15
Replacement Double Hungs
LAMI 80
N/A
36
30
ESP025396P-11
Replacement Double Hungs
LAMI 82
N/A
36
29
ESP025396P-14
Replacement Double Hungs
Triple Insulated Glass, 3.1mm - 3.1mm - 4.7mm
N/A
35
29
ESP025396P-13
Studio Replacement Double Hungs
Insulated Glass, 3.1mm - 3.1mm
N/A
29
24
ESP025396P-31
Studio Replacement Double Hungs
Insulated Glass, 5.7mm - 3.1mm
N/A
33
28
ESP025396P-32
Studio Replacement Double Hungs
LAMI 82
N/A
34
27
ESP025396P-33
Studio Replacement Double Hungs
LAMI 85
N/A
35
31
ESP025396P-35
Studio Replacement Double Hungs
Triple Insulated Glass, 3.1mm - 3.1mm - 4.7mm
N/A
33
28
ESP025396P-34
Replacement Sliding Windows
Insulated Glass, 3.1mm - 3.1mm
N/A
29
24
ESP025396P-41
Replacement Sliding Windows
Insulated Glass, 5.7mm - 3.1mm
N/A
36
30
ESP025396P-42
Replacement Sliding Windows
LAMI 80
N/A
35
30
ESP025396P-45
Replacement Sliding Windows
LAMI 82
N/A
34
29
ESP025396P-43
Replacement Sliding Windows
Triple Insulated Glass, 3.1mm - 3.1mm - 4.7mm
N/A
35
30
ESP025396P-44
Back to top

Heritage Series

PRODUCT

GLASS

COMBO

STC

OITC

Report

Outswing Commercial Doors
7/8" IG (standard)
N/A
32
26
ESP017293P-19
Outswing Commercial Doors
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
35
30
ESP017293P-21
Outswing Commercial Doors
LAMI 27 (7/8" IG Impact Resistant Lami Glass)
N/A
34
31
ESP017293P-20
Outswing 2.25" Panel Commercial Doors
7/8" IG (standard)
N/A
31
26
ESP017293P-22
Outswing 2.25" Panel Commercial Doors
Sound Control Lami 43
N/A
39
33
ESP017293P-23
Outswing 2.25" Raised Panel Commercial Doors
Sound Control Lami 43
N/A
36
32
ESP017293P-24
Inswing Entrance Doors
7/8" IG (standard)
N/A
32
26
ESP017293P-28
Inswing Entrance Doors
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
35
29
ESP017293P-29
Inswing Entrance Doors
LAMI 27 (7/8" IG Impact Resistant Lami Glass)
N/A
35
30
ESP017293P-30
Inswing 2.25" Panel Entrance Doors
7/8" IG (standard)
N/A
31
25
ESP017293P-16
Inswing 2.25" Panel Entrance Doors
Sound Control Lami 43
N/A
39
32
ESP017293P-17
Inswing 2.25" Raised Panel Entrance Doors
Sound Control Lami 43
N/A
36
32
ESP017293P-18
Outswing Entrance Doors
7/8" IG (standard)
N/A
32
26
ESP017293P-19
Outswing Entrance Doors
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
35
30
ESP017293P-21
Outswing Entrance Doors
LAMI 27 (7/8" IG Impact Resistant Lami Glass)
N/A
34
31
ESP017293P-20
Outswing 2.25" Panel Entrance Doors
7/8" IG (standard)
N/A
31
26
ESP017293P-22
Outswing 2.25" Panel Entrance Doors
Sound Control Lami 43
N/A
39
33
ESP017293P-23
Outswing 2.25" Raised Panel Entrance Doors
Sound Control Lami 43
N/A
36
32
ESP017293P-24
Sliding Patio Doors
7/8" IG (standard)
N/A
31
28
ESP017525P-4
Sliding Patio Doors
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
31
28
ESP017525P-3
Sliding Patio Doors
LAMI 27 (7/8" IG Impact Resistant Lami Glass)
N/A
33
29
ESP017525P-1
Crank-Out Casements
7/8" IG (standard)
N/A
28
RAL_TL_98-206
Crank-Out Casements
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
35
RAL_TL_98-207
Crank-Out Casements
SPECIAL GLAZING - SEE REPORT
N/A
35
RAL_TL_98-205
Sterling Double Hungs
7/8" IG (standard)
N/A
28
23
30160-05-63843
Sterling Double Hungs
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
31
27
30160-05-63843
Sterling Double Hungs
LAMI 28 (7/8" IG Impact Resistant Lami Glass)
N/A
32
27
30160-05-63843
Back to top

Ultra Series

PRODUCT

GLASS

COMBO

STC

OITC

Report

Outswing Commercial Doors
7/8" IG (standard)
N/A
31
26
ESP017293P-10
Outswing Commercial Doors
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
34
29
ESP017293P-11
Outswing Commercial Doors
LAMI 27 (7/8" IG Impact Resistant Lami Glass)
N/A
35
31
ESP017293P-12
Outswing 2.25" Panel Commercial Doors
7/8" IG (standard)
N/A
31
26
ESP017293P-13
Outswing 2.25" Panel Commercial Doors
Sound Control Lami 43
N/A
38
32
ESP017293P-14
Outswing 2.25" Panel Commercial Doors
Sound Control Lami 43
N/A
37
33
ESP017293P-15
Direct Sets
7/8" IG (standard)
N/A
31
27
ESP17526P-29
Direct Sets
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
34
29
ESP17526P-28
Direct Sets
LAMI 34 (7/8" IG Impact Resistant Lami Glass)
N/A
36
33
ESP17526P-27
Inswing Entrance Doors
7/8" IG (standard)
N/A
32
26
ESP017293P-7
Inswing Entrance Doors
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
34
30
ESP017293P-8
Inswing Entrance Doors
LAMI 27 (7/8" IG Impact Resistant Lami Glass)
N/A
34
31
ESP017293P-9
Inswing 2.25" Panel Entrance Doors
7/8" IG (standard)
N/A
31
25
ESP017293P-25
Inswing 2.25" Panel Entrance Doors
Sound Control Lami 43
N/A
37
31
ESP017293P-26
Inswing 2.25" Raised Panel Entrance Doors
Sound Control Lami 43
N/A
36
32
ESP017293P-27
Outswing Entrance Doors
7/8" IG (standard)
N/A
31
26
ESP017293P-10
Outswing Entrance Doors
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
34
29
ESP017293P-11
Outswing Entrance Doors
LAMI 27 (7/8" IG Impact Resistant Lami Glass)
N/A
35
31
ESP017293P-12
Outswing 2.25" Panel Entrance Doors
7/8" IG (standard)
N/A
31
26
ESP017293P-13
Outswing 2.25" Panel Entrance Doors
Sound Control Lami 43
N/A
38
32
ESP017293P-14
Outswing 2.25" Panel Entrance Doors
Sound Control Lami 43
N/A
37
33
ESP017293P-15
Sliding Patio Doors
7/8" IG (standard)
N/A
28
23
ESP017525P-6
Sliding Patio Doors
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
33
28
ESP017525P-5
Sliding Patio Doors
LAMI 27 (7/8" IG Impact Resistant Lami Glass)
N/A
33
29
ESP017525P-2
Crank-Out Casements
7/8" IG (standard)
N/A
29
24
30160-08-96083-2
Crank-Out Casements
LAMI 11 (Single Glazed Impact Resistant Glass)
N/A
35
31
30160-08-96083-2
Crank-Out Casements
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
33
27
30160-08-96083-2
Crank-Out Casements
LAMI 25 (7/8" IG Impact Resistant Lami Glass)
N/A
34
29
30160-08-96083-2
Fixed Crank-Out Casements
7/8" IG (standard)
N/A
29
24
30160-08-96083-1
Fixed Crank-Out Casements
LAMI 14 (Single Glazed Impact Resistant Glass)
N/A
33
32
30160-08-96083-1
Fixed Crank-Out Casements
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
33
27
30160-08-96083-1
Fixed Crank-Out Casements
LAMI 27 (7/8" IG Impact Resistant Lami Glass)
N/A
34
29
30160-08-96083-1
XL Crank-Out Casements
1-3/8" Triple IG
N/A
29
23
TCT004380P
XL Crank-Out Casements
Sound Control Lami 43
N/A
39
33
TCT004380P
Double Sliding Sliding Windows
7/8" IG 3.1MM ANN, 3.1MM ANN
N/A
27
22
ESP024741P-9
Double Sliding Sliding Windows
LAMI 57
N/A
32
30
ESP024741P-8
Quad Sliding Sliding Windows
7/8" IG 3.1MM ANN, 3.1MM ANN
N/A
27
22
ESP024741P-9
Quad Sliding Sliding Windows
LAMI 57
N/A
32
30
ESP024741P-8
Single Sliding Sliding Windows
7/8" IG 3.1MM ANN, 3.1MM ANN
N/A
27
22
ESP024741P-9
Single Sliding Sliding Windows
LAMI 57
N/A
32
30
ESP024741P-8
Sterling Double Hungs
7/8" IG (standard)
N/A
28
22
30160-04-61466
Sterling Double Hungs
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
32
26
30160-04-61466
Sterling Double Hungs
LAMI 25 (7/8" IG Impact Resistant Lami Glass)
N/A
32
27
30160-04-61466
Sterling Double Hungs
SPECIAL GLAZING - SEE REPORT
N/A
30
26
30160-04-61466
Fixed Sterling Double Hungs
7/8" IG (standard)
N/A
28
23
30160-04-63301
Fixed Sterling Double Hungs
LAMI 11 (Single Glazed Impact Resistant Glass)
N/A
34
32
30160-04-63301
Fixed Sterling Double Hungs
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
34
29
30160-04-63301
Fixed Sterling Double Hungs
LAMI 27 (7/8" IG Impact Resistant Lami Glass)
N/A
35
30
30160-04-63301
Triple Sliding Sliding Windows
7/8" IG 3.1MM ANN, 3.1MM ANN
N/A
27
22
ESP024741P-9
Triple Sliding Sliding Windows
LAMI 57
N/A
32
30
ESP024741P-8
Back to top

VistaLuxe WD LINE

PRODUCT

GLASS

COMBO

STC

OITC

Report

Awnings
7/8" IG (standard)
N/A
30
25
ESP017527P-8
Casements
7/8" IG (standard)
N/A
29
26
ESP17526P-31
Casements
Sound Control Lami 43
N/A
35
32
ESP17526P-40
Fixed Casements
7/8" IG (standard)
N/A
31
27
ESP17526P-32
Fixed Casements
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
33
29
ESP17526P-39
Fixed Casements
Sound Control Lami 43
N/A
39
34
ESP17526P-30
Direct Sets
7/8" IG (standard)
N/A
31
27
ESP17526P-38
Direct Sets
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
33
29
ESP17526P-33
Direct Sets
Sound Control Lami 43
N/A
40
34
ESP17526P-33
Inswing Entrance Doors
7/8" IG (standard)
N/A
32
26
ESP017293P-7
Inswing Entrance Doors
7/8" IG (standard)
N/A
31
25
ESP017293P-1
Inswing Entrance Doors
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
36
30
ESP017293P-2
Inswing Entrance Doors
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
34
30
ESP017293P-8
Inswing Entrance Doors
LAMI 27 (7/8" IG Impact Resistant Lami Glass)
N/A
34
31
ESP017293P-9
Inswing Entrance Doors
Sound Control Lami 43
N/A
37
33
ESP017293P-3
Inswing 2.25" Panel Entrance Doors
7/8" IG (standard)
N/A
31
25
ESP017293P-25
Inswing 2.25" Panel Entrance Doors
Sound Control Lami 43
N/A
37
31
ESP017293P-26
Inswing 2.25" Raised Panel Entrance Doors
Sound Control Lami 43
N/A
36
32
ESP017293P-27
Outswing Entrance Doors
7/8" IG (standard)
N/A
30
25
ESP017293P-4
Outswing Entrance Doors
LAMI 20 (7/8" IG with 1/4" Lami)
N/A
35
30
ESP017293P-5
Outswing Entrance Doors
Sound Control Lami 43
N/A
39
35
ESP017293P-6
Outswing 2.25" Panel Entrance Doors
7/8" IG (standard)
N/A
31
26
ESP017293P-13
Outswing 2.25" Panel Entrance Doors
Sound Control Lami 43
N/A
37
33
ESP017293P-15
Outswing 2.25" Panel Entrance Doors
Sound Control Lami 43
N/A
38
32
ESP017293P-14
Double Sliding Sliding Windows
7/8" IG 3.1MM ANN, 3.1MM ANN
N/A
27
22
ESP024741P-9
Double Sliding Sliding Windows
LAMI 56
N/A
32
30
ESP024741P-8
Quad Sliding Sliding Windows
7/8" IG 3.1MM ANN, 3.1MM ANN
N/A
27
22
ESP024741P-9
Quad Sliding Sliding Windows
LAMI 56
N/A
32
30
ESP024741P-8
Single Sliding Sliding Windows
7/8" IG 3.1MM ANN, 3.1MM ANN
N/A
27
22
ESP024741P-9
Single Sliding Sliding Windows
LAMI 56
N/A
32
30
ESP024741P-8
Triple Sliding Sliding Windows
7/8" IG 3.1MM ANN, 3.1MM ANN
N/A
27
22
ESP024741P-9
Triple Sliding Sliding Windows
LAMI 56
N/A
32
30
ESP024741P-8
Back to top

IG = Insulating Glass
STC = Sound Transmission Class
OITC = Outdoor-Indoor Transmission Class
COMBOS = Combination Storm/Screen Units

Contact Us

Can't seem to find what you are looking for? Get in touch with one of our experts! Fill out the form below or call us at 715-842-5666.
